The ultimate
rejuvenation station

QUADROSTAR®

PRO YELLOW®

The world's first pure yellow 577nm laser for safe & effective treatment of both light & dark skin types (I - V).


Industry Leading

2 Year Extended Warranty


Yellow = Safer, more
Permanent results.

The ProYellow 577nm laser is the ideal laser for targeting skin lesions. It penetrates deeper than conventional lasers, simultaneously addressing both visible lesions and underlying structures. This translates to safer, more permanent results and fewer side effects for both light & darker pigmented skin.

  • Ability to treat both light & dark skin types (1 - 5)

  • A wider range of indications

  • Reduced risk of side effects

  • Greater comfort

  • Shorter healing period

Treatment Options

Compared to other wavelengths, the 577nm ProYellow laser can non-invasively treat a broad range of indications, with immediate results and little risk to patients.


List of Indications

The ProYellow is now the preferred laser by a growing number of key opinion leaders for the indications below:

• melasma
• fractionated rejuvenation
• active acne vulgaris
• benign moles
• cherry angioma
• couperosis
• fibromas
• fine lines (wrinkle reduction)

• hemangioma

• lentigines

• plantar warts

• poikiloderma of civatte

• port wine stains

• post-acne erythema

• post-inflammatory hyperpigmentation (PIH)

• pyogenic granuloma

• rosacea (diffuse facial redness)

• scar revision

• sebaceous hyperplasia

• seborrheic kerotisis
• skin tags
• spider nevus
• spider angioma
• telangiectasia
• venous lake
• verruca vulgaris (warts)
• wrinkles
• syringoma
• xanthelasma

Fractional Scanner with integrated contact cooling

The ProYellow scanner allows for fractional treatments of large areas. The scanned area, measuring 15 x 15 mm, can be set with the following shapes and at varying spot densities:


The scanner also features a highly efficient integrated skin cooling with a sapphire coated window.


Spot Handpieces

The ProYellow features three standard handpieces with varying spot sizes - designed for tracing single vessels and vaporizing cutaneous lesions.



Spot sizes included:

  • 0.5mm, 1.0mm & 1.5mm

  • Optional: 2.8mm

Specifications

LASER TYPE

WAVELENGTH

POWER

PULSE LENGTH

FREQUENCY

MODES

SPOT HANDPIECES

SCANNER HANDPIECE

SIZE

WEIGHT

HOPSL** (577nm diode)

FDA Class 4, Health Canada Class 3

577nm

Max. 5 Watts

1ms - Continuous Wave (CW)

0.5 - 20Hz

Basic, Expert, CW, Scan

Standard: 0.5mm, 1.0mm, 1.5mm

Optional: 2.8mm

Spot size: 1.0mm

Pattern Area: 15mm x 15mm (max)

Adjustable spot density

7 scan shapes & sizes

42cm x 38cm x 19cm (WxDxH)

< 12kg (26 lbs)

* All specifications subject to change without notice.

** High-Powered Optically Pumped Semiconductor Laser

Get Started

Book a free 'hands-on' onsite demonstration with one of our laser specialists.



Also, feel free to send us any clinical, technical, or financial questions. We're here to help.
